Jetson Examples Quick Start

Introduction

The jetson-examples repository by Seeed Studios provides pre-built, ready-to-run AI examples for NVIDIA Jetson devices. Instead of spending hours setting up environments and dependencies, you can deploy complex AI models with a single command using Docker containers.

This module shows you how to use the jetson-examples CLI tool to quickly deploy LLMs and other AI models on your Jetson device.

What is jetson-examples?

jetson-examples is a command-line tool that:

• Provides one-line deployment for popular AI models
• Uses Docker containers for isolated, reproducible environments
• Includes pre-optimized configurations for Jetson hardware
• Supports multiple frameworks: PyTorch, TensorRT, Ollama, and more

Installation

Install the CLI Tool

# Install jetson-examples via pip
pip3 install jetson-examples

# Verify installation
reComputer --help

Alternative: Manual Docker Setup

If you prefer manual control:

# Install Docker (if not already installed)
sudo apt-get update
sudo apt-get install -y docker.io

# Add user to docker group (requires logout/login)
sudo usermod -aG docker $USER

# Verify Docker
docker --version

Available LLM Examples

Here are the LLM-related examples available in the jetson-examples repository:

Text-Only LLMs

Vision-Language Models (VLM)

Audio & Speech

Inference Server

Getting Started

Example 1: Running Ollama

The quickest way to start with LLMs on Jetson:

# Deploy Ollama with Docker
reComputer run ollama

Once running, you can pull and run models:

# Enter the Docker container
docker exec -it ollama bash

# Pull and run a model
ollama run llama3.2:3b

Example 2: Running a Vision-Language Model

# Deploy LLaVA for image understanding
reComputer run llava-v1.5-7b

This sets up a model that can understand and describe images.

Example 3: Deploying Text Generation WebUI

For a full-featured web interface to interact with LLMs:

# Deploy text-generation-webui (Oobabooga)
reComputer run text-generation-webui

Access the web interface at http://localhost:5000.

Example 4: Deploying Whisper for Speech Recognition

# Deploy OpenAI Whisper for speech-to-text
reComputer run whisper

Practical Example: Building a Chatbot

Let's put it all together to create a simple chatbot using jetson-examples:

Step 1: Deploy Ollama

reComputer run ollama

Step 2: Pull a Model

# Check running containers
docker ps

# Enter the Ollama container
docker exec -it ollama ollama pull llama3.2:3b

Step 3: Test via API

# Test the chat API
curl http://localhost:11434/api/chat -d '{
  "model": "llama3.2:3b",
  "messages": [
    {"role": "user", "content": "What can you help me with?"}
  ],
  "stream": false
}'

Step 4: Python Integration

import requests

def chat_with_model(user_message, model="llama3.2:3b"):
    response = requests.post(
        "http://localhost:11434/api/chat",
        json={
            "model": model,
            "messages": [{"role": "user", "content": user_message}],
            "stream": False
        }
    )
    return response.json()["message"]["content"]

# Interactive chat
while True:
    user_input = input("You: ")
    if user_input.lower() in ['quit', 'exit', 'q']:
        break
    response = chat_with_model(user_input)
    print(f"AI: {response}\n")

Managing Containers

Common Docker Commands

# List running containers
docker ps

# List all containers (including stopped)
docker ps -a

# View container logs
docker logs <container-name>

# Stop a container
docker stop <container-name>

# Restart a container
docker restart <container-name>

# Remove a container
docker rm <container-name>

# Enter a running container
docker exec -it <container-name> bash

Resource Monitoring

# Monitor container resource usage
docker stats

# Check disk usage
docker system df

Customizing Deployments

Environment Variables

Many examples support configuration via environment variables:

# Example: Setting model parameters for Ollama
docker run -d \
  --name ollama \
  --gpus all \
  -e OLLAMA_HOST=0.0.0.0:11434 \
  -p 11434:11434 \
  ollama/ollama:latest

Volume Mounts

Persist data between container restarts:

# Mount a local directory for model storage
docker run -d \
  --name ollama \
  --gpus all \
  -v /path/to/models:/root/.ollama \
  -p 11434:11434 \
  ollama/ollama:latest

Network Configuration

Access services from other devices on your network:

# Bind to all interfaces (not just localhost)
docker run -d \
  --name ollama \
  --gpus all \
  -p 0.0.0.0:11434:11434 \
  ollama/ollama:latest

Performance Tips

1. Use GPU Passthrough

Always ensure Docker has GPU access:

# Verify GPU access in container
docker exec -it <container-name> nvidia-smi

2. Allocate Appropriate Memory

# Limit container memory (optional, for multi-container setups)
docker run -d \
  --name ollama \
  --gpus all \
  --memory=12g \
  --memory-swap=16g \
  ollama/ollama:latest

3. Use SSD Storage

Models load faster from SSD than SD card or eMMC.

Common Issues and Solutions

Issue 1: Docker Permission Denied

Problem: Got permission denied while trying to connect to the Docker daemon socket

Solution:

# Add user to docker group
sudo usermod -aG docker $USER

# Log out and log back in for changes to take effect
# Or run in current session:
newgrp docker

Issue 2: Container Won't Start

Problem: Container exits immediately after starting

Solution:

# Check container logs for errors
docker logs <container-name>

# Check available resources
free -h
df -h
nvidia-smi

Example Repositories and Projects

Explore these examples from the jetson-examples repository:

llama-factory

Fine-tune LLMs on your Jetson device:

reComputer run llama-factory

Model/data size: 13.5GB

live-vlm-webui

Real-time vision-language model interface:

reComputer run live-vlm-webui

Features: Live camera feed processing with AI understanding

deep-live-cam

Real-time face swap and processing:

reComputer run deep-live-cam

Practice Exercise

1. Install jetson-examples tool
2. Deploy Ollama and run llama3.2:3b
3. Deploy LLaVA for image understanding
4. Create a Python script that interacts with the deployed model
5. Set up Open WebUI for a graphical interface
6. Explore other examples in the repository

References

• jetson-examples Repository - Official repository
• jetson-examples Documentation - Complete example list
• Docker Documentation - Docker fundamentals
• NVIDIA Container Toolkit - GPU support in Docker
• Ollama Documentation - Ollama usage guide

Next: Continue to Module 5.6: Building ASR + LLM + TTS Pipeline to create a complete voice assistant!
